Overview Of Youcan Food Stainless Steel Tank Semi-trailer
Food Stainless Steel Tank Trailer is also called Tanker for food or Edible Liquid Tanker, used for transport liquid food: milk, water,diesel, etc.The tank body material is stainless steel.
The volume of the Stainless Steel tankers can be customized, to reach 40,000 liters, 45,000 liters, 54,000 liters, up to 90,000 liters. With different numbers of compartments(1-2-3..6 or more), and 2-3-4 axles to meet the different regulatory requirements of different countries.
Our pioneering views on the transport of liquid derivatives in road transport of dangerous goods, our dominance and our accumulated knowledge, have changed the standard of the industry it serves, and our premium tankers have numerous design approvals from An international authority, vehicle, driver and road safety, always at the forefront of filling, transporting and unloading operations, we minimise environmental risks and user liability. We have increased user ergonomics through safety measures on the tanker, making high dynamic loads safe and portable in difficult conditions.
Features of Youcan Stainless Steel Tank Trailer
1. CAE and Hypermesh software were used for multiple finite element analysis and verification to optimize the structure of the tanker and its components.
2. The frame adopts high strength stainless steel and the latest lightweight structure design to ensure the strength of the frame while reducing the weight to the lightest.
3. Use of robotic welding technology: The tank body is automatically welded by an advanced robot welding machine, incerases the body strength at chassis joints, reduces tension effect, provides unity of body.
4. Armature discharge box’s cover: Provides mobility and ergonomic handling even in the narrow area.
5. Performance needs source -Durable body structure, superior production technology and premium equipment, turn into long lifetime income.
6. Gooseneck cross section design conforms to EN 13094 standard
You determine the content, compartments and the usage of baffles in our stainless steel food tankers.We produce our tank semi-trailers from both stainless steel 1.4404 (316L) and 1.4301 (304).Normally, these tank trailers are non-ADR, but food-ADR remains a possibility.
Cleaning and hygiene
Stainless steel food tankers require a higher level of inside finishing grade then ADR tanks.That's why we polish the welding seams of food tanks on the inside (in accordance with nutritional requirements).This improves the cleanability and hygiene.
Stainless Steel Tank Trailer Supplier
Youcan Trailer is a professional semi-trailer manufacturer providing complete semi-trailer solutions for almost all types of trucks on different applications. The company specialized in providing liquid tank trailers, fuel tankers, chemical tankers, bulk cement tank trailers, tipper trailers, stake storage semi-trailers, flatbed semi-trailers, low-bed semi-trailers, container carrier trailers, curtainsider trailers, and other hundreds of products. Feel free to contact us for latest price of new semi-trailers. Competitive price with reliable quality waiting for you!
Youcan Stainless Steel Tanker For Food
6000 kg-9500 kg
Number Of Compartment
Construction Material Serial: Stainless Steel
Discharge box position
Rubber box tube
Unloading hose size
Middle Side/tail side
Round PVC/stainless steel pipe
5.7M discharge hose
Open overflow box/double-cover overflow box/single-cover overflow box
One per compartment, 6 in total
Pressure Vacuum Vent
One per compartment, roll-over type incorporates with manhole.
One per compartment, 20" manhole cover with Fill/emergency vents, pressure vacuum vents, overfill holes and vapour transfer vent hole.
Axle brand and number
2/3/4 Axles, BPW or YOUCAN
50# or 90#
Air suspension with front lifting / Mechanical
8/12/16 sets 12R22.5, 315/80R22.5, 385/80R22.5
Jost/Youcan 28T, double speed operation
Dual Line braking system , Wabco ABS.
Brake air chamber
Four double Two single
24V,7 pin socket,One set 6-core standard Cable
Tail lamp with turn signal, brake light & reflector
side lamp etc
Spare tire carrier
Polish with wax before shipping
*The product type and optional equipment can vary depending on your choice.
