Overview of Youcan Container Chassis

A Container Chassis is also called Skeletal Trailer, used for transporting containers including 20ft 40ft 45ft.The structure of the Container Chassis is straight beam or gossenneck frame.  Mainly used for multimodal transport supporting logistics system including ship, port, air route, highway, transfer station, bridge, tunnel.

What is a Container Chassis trailer

One of the challenges of using containers in transportation is that the containers come in different size. Hence, some containers require special vehicles for transportation because of their dimensions.

Companies require a transport solution that can adopt to different sizes and types of containers. In addition, many states have implemented bridging laws, which define the distance between the rear and front wheels of heavy-duty vehicles.

Container chassis trailer are designed to overcome these challenges.

Why the Container Chassis Trailer?

The need for a truck chassis capable of taking high weight containers without loading and offloading issues prompted such a design. This is what you will be going for if you have such needs.

Again, the container chassis trailer provides you with the option of taking high weight container while at the same time giving you options to make adjustments to desirable maneuverability.

This type of trailer is a simple yet strong and is capable to serve you even in rugged topography.

One defining characteristic of the chassis trailer is the fact that it can transport different sizes of containers such as the 45ft, 40ft and the 20ft long containers.

2.2 Key Advantages of the Chassis Trailer

It is a cheap and affordable construction

It is a light and solidly firm structure

It uses fewer material and yet carries heavy cargo

It is built from high strength structural material making it a rigid construction, good for its application

The chassis trailer for your container is available in different models. You can choose what matches your needs because the functions are the same.

It is commonly used for container transportation

2.3 Common Chassis

This is a fixed structure commonly used in the transportation of containers. It is mainly of a steel construction where containers are loaded and offloaded using overhead cranes.

It has a landing gear that is used to enhance stability during loading and offloading operations.

It can be used for loading and transporting 20ft, 40ft and 45ft container. With well-marked positions, you can load your container and move it to your desired destination with ease.

It is simple to use and most importantly, affordable. However, the need for external accessories could possibly delay the operations.

2.4 Load Positioning Chassis

Trailer has a long chassis that is supported to one end through a movable bogie unit or a slider with an attached sliding bolster unit

It comes with retractable roller mechanisms on the said bogie unit and the bolster unit urged against the trailer chassis. This allows easy placement of a unit at a suitable position along the trailer chassis

It also comes with a releasable coupling in between bolster and the slider to allow the bolster to travel along the chassis through the slider

Features of Youcan Container Chassis

1.CAE and Hypermesh software were used for multiple finite element analysis and verification to optimize the structure of the vehicle and its components.

2.The YOUCAN Container Chassis is automatically welded by an advanced large-scale special welding machine. Ensure the safety of the trailer and increase the service life.

3.The metal surfaces of the vehicle after the welding process is cleaned with sand shot blasting process with grit metal.In order to protect the surfaces from rusting on the top of the surfaces with 2 coats of epoxy primer and acrylic finished paint will be on customer demand. The total thickness of the paint work is 120micron.

4.Performance needs source -Durable body structure, superior production technology and premium equipment, turn into long lifetime income.

Container Chassis trailer Supplier

The Youcan Trailer was founded in 1999, with rich experiences of producing semi-trailers and providing complete trailer solutions for different applications. The company specialized in providing aluminum tankers, fuel tankers, bulk cement tankers, dumper trailers,tipper trailers, stake/sidewall trailers, flatbed trailers, low-bed trailers, container carrier trailers, cargo trailers, and other hundreds of products with 23 Years of experiences. Feel free to contact us for latest price of new semi-trailers. Competitive price with reliable quality waiting for you!
